#655666 - 03/01/05 02:43 PM HVAC Fan Controller only works on "high" selector
fastsvo Offline
Member

Registered: 10/29/03
Posts: 285
Hope this is the right place for this.

My '94 Vic recently only likes to blow air when on the most powerful setting only. THe lower speeds don't work at all.

Where should I start looking? Could this be a simple fuse? Thanks.

-Eric

Top
Links
#655667 - 03/01/05 02:46 PM Re: HVAC Fan Controller only works on
Sully008 Offline
Member

Registered: 10/15/04
Posts: 257
Loc: Winnipeg, Mb., Canada
It sounds like the blower motor resistor's gone south. I think it's attached to the blower motor under the glove box. Unfortunately, I don't own a '94 so I'm not positive on the location.
_________________________
Mike


'03 Black Mercury Marauder 300A -#6018 of 11,052
Trilogy S/C #196. Stuff done to it.

Top
#655668 - 03/01/05 03:28 PM Re: HVAC Fan Controller only works on
Chevyguy Offline
Poobah

Registered: 01/04/04
Posts: 8167
Loc: Winchester Mass
The blower motor resistor is on the firewall, pass side Check that first.

For my car the HVAC head unit itself was the problem. I only had High and second from low. Replaced HVAC head unit from Junkyard (this was replaced in that car from another one, it had a junkyard mark already!!) Now I have all the speeds, and High blows much better too!!
_________________________
2004 MarauderM79 104K miles Jmod!! Lidio 93 tune for the track BOC 91 octane street tune 14.85 @95.63
2004 Crown Vic LX 145K Silver Birch Light flint leather FMX1 04 P-71 PCM swap 70 mm TB Custom shorting wire harness. 28/ 21mm MM swaybars Monroe severe duty shocks. Marauder subwoofer and painted cap heated mirrors. GT-500 Wheels NEED DUAL EXHAUST


Project car 74 Chevy Laguna type S-3, # match 400 SBC

Previous rides
93 P-71 2001 P-73, 94 TC Exec, 96 TC Signature

Top
#655669 - 03/01/05 08:44 PM Re: HVAC Fan Controller only works on
00P71CrownVic Offline
Member

Registered: 11/18/04
Posts: 162
Loc: Earlham Iowa
my 2000 has been doing the exact same thing now for about 5 months but I have just been living with it
_________________________
2000 White Crown Vic P71
Alpine CDA-9831 CD player XM Radio
Steeda UD Pulleys
3.55 gears
BearCat Police Scaner
cobra CB
5ft whip
Wig-wags
GatorBack belt
GoodYear Eagle GA's

Top
#655670 - 03/01/05 09:15 PM Re: HVAC Fan Controller only works on
fastsvo Offline
Member

Registered: 10/29/03
Posts: 285
Cool, so I assume this resistor is inside the vehicle and not in the engine compartment?

Where can I get a replacement resistor from? There is a huge wharehouse here that makes nothing but fuses, maybe they will have the part.

Thanks

Eric

Top
#655671 - 03/01/05 11:13 PM Re: HVAC Fan Controller only works on
Steve83 Offline
Poobah

Registered: 10/03/04
Posts: 7445
Loc: Memphis, TN 38002, USA, Earth,...
The resistor is in the engine bay just R of center at the back just below the wiper & beside the heater hoses. It's mounted in the air duct by 2 screws, but the connector is usually a B!T(# to unplug. This pic is fuzzy, but it's between the upper heater core nipple & the hose with the red sticker.

_________________________
Walk softly & carry a BIG SIX ! ! !

. . .

Top
#655672 - 03/02/05 11:49 AM Re: HVAC Fan Controller only works on
fastsvo Offline
Member

Registered: 10/29/03
Posts: 285
Sweet!

Anyway to test the resistor with a DVM?

Thanks.

Eric

Top
#655673 - 03/02/05 02:08 PM Re: HVAC Fan Controller only works on
LTDteether Offline
Over the Hill

Registered: 07/19/02
Posts: 4450
Loc: Democratic Rep. of Southpaw
It is not a simple resistor, but a BLOWER MOTOR RESISTOR ASSEMBLY -- Four speeds, three resistors. There is a relay that defaults to high speed if the temp gets too high , IIRC. You might be able to repair it, but most people just yank it our and replace it for about 17 bucks. N.B., the assembly is different for manual control v.s. EATC.

You could just have a connector problem at that assembly.
_________________________
'99 GM GS HPP.
I may not be a rocket scientist, but I *am* a scientist.

Top
#655674 - 03/02/05 10:59 PM Re: HVAC Fan Controller only works on
fastsvo Offline
Member

Registered: 10/29/03
Posts: 285
Ahh...thanks for the update.

So I take it this is a dealer item only? Anyone have a part #? Thanks.

Eric

Top
#655675 - 03/03/05 02:15 PM Re: HVAC Fan Controller only works on
LTDteether Offline
Over the Hill

Registered: 07/19/02
Posts: 4450
Loc: Democratic Rep. of Southpaw
In my 99 manual: E3AZ19A706A if you have knobs.

In case you do want to try to diagnose it, not that this is on the ground side of the motor. There are three resistors in my diagram, two-0.5 ohm and one-1.3 ohm. It looks like low speed uses all three, the next uses both 0.5s and the penultimate speed uses one of the 0.5s. .
_________________________
'99 GM GS HPP.
I may not be a rocket scientist, but I *am* a scientist.

Top
#655676 - 03/03/05 10:00 PM Re: HVAC Fan Controller only works on
RussianCelery Offline
Member

Registered: 10/16/03
Posts: 353
Loc: 'Burbs of Chicago
Yeah, its the blower motor resistor assembly; mine went out last summer at 150k '95. I reccomend removing the tree of vaccum lines that goes to some assembly right above it on the cowl in order to have easier access. Just use a 1/4" Ratchet, and realize its not the easiest fit; I could replace it in 15 minutes, and while your doing that since you have time and already unplugged your battery... Clean your MAF and do yourself the favor!

Top
#655677 - 08/22/05 12:36 AM HVAC Autotemp Works on High Only
Taxman100 Offline
Over the Hill

Registered: 04/17/04
Posts: 3572
Loc: Ohio
Is this solution the same if you have the older EATC system with the sliding buttons in a 1994 Grand Marquis?

My A/C blows plenty cold, but it works only when the buttons are slid to the AUTO setting, and the temparature button is slid to the 65 degree position.

Is the repair the same on an autotemp vs manual system for a 1994? I am willing to try to replace a $17 part on my own, but if it requires taking apart the dashboard, I'm not that hardcore of a DIY.

I love my old GM, but it's not like I'm keeping it because I cannot afford a new one - so if it starts to rack up too much repairs, I'll probably trade her in. I'd send her to a new owner at the same time I can joyfully dump my POS Dodge Intrepid on some poor sap.
_________________________
--------------------------------
2011 Volkswagen Routan SE w/RSE - family truckster
2002 Grand Marquis LSE - 132k
2000 Corolla CE - 182k - temporarily off the road
1967 Galaxie 500XL convertible - 36k of old school

Top
#2717455 - 06/03/13 04:29 PM Re: HVAC Autotemp Works on High Only [Re: fastsvo]
Dairenn Offline
Climber

Registered: 12/12/05
Posts: 993
Loc: Los Angeles, CA
This was the blower motor relay in my 2006 Crown Victoria LX. It failed after approximately 68,000 miles (manufactured February, 2006, went out May, 2013). The issue was the EATC fan controller only has two ways of working: off, and, full blast. No button or dial manipulation could fix it, and the EATC self-diagnostic returned no codes, so it wasn't the EATC controller itself. Hope this fact helps someone out somewhere out there.
_________________________
~ Dairenn Lombard
(All-stock CVLX06)

Top
